8440-2167

SPM-D2-1010B/YB

CONTROL-SPM-D2-1010B/YB

The SPM-D2-101010B/YB is a microprocessor-based synchronizer designed for use on single phase AC generators equipped with Woodward or other compatible speed controls and automatic voltage regulators. The SPM-D2-10-1010B/YP synchronizer provides automatic frequency, phase and voltage matching using either analog or discrete output bias signals. These synchronizers are applied to a wide range of prime movers and generators, as their control signals may be set to fit several types of gensets -- from fast-reacting diesel engines to soft-reacting gas turbines.
Product Type
  • Application Notes
  • Brochure
  • Product Specification
  • Software Manual
  • Technical Manual
  • Software
FEATURES & FUNCTIONALITY
The SPM-D2-10 series are microprocessor-based synchronizers designed for use on three phase AC generators equipped with Woodward or other compatible speed controls and automatic voltage regulators. The SPM-D2-10 synchronizers provide automatic frequency, phase and voltage matching using either analog or discrete output bias signals. The SPM-D2-10 provides 1-phase / 2-wire voltage measurement with options for analog or discrete biasing signals and wide range power supply.  These synchronizers are applied to a wide range of prime movers and generators, as their control signals may be set to fit several types of gensets -- from fast-reacting diesel engines to soft-reacting gas turbines.

All SPM-D2 synchronizers are password protected and configurable either through HMI (as were the SPM-D units) or through the ToolKit configuration tool with USB connectivity.

Benefits:
  • Compatible with a wide range of governors, automatic voltage regulators, and circuit breakers
  • True RMS voltage sensing for reduced susceptibility to harmonics
  • Front face synchroscope for easy commissioning
  • HMI programming and USB connectivity to Woodward ToolKit service tool
  • Drop-in replacement for existing SPM-D10 synchronizers

Features:

  • Synchronization for one or two circuit breakers
  • Phase match or slip frequency synchronization with voltage matching
  • Three position/analog outputs for speed and voltage bias signals
  • Circuit breaker time compensation
  • Discrete inputs for operating mode selection
  • Two-line liquid crystal text display for operation, alarm indication, and visualization of measuring values
  • LED synchroscope
  • Wide range power supply option available
  • PC and front panel configurable
