Product Variants
SPM-D2 10
SPM-D2 11
breakers synchronized
1 or 2
1
AC phases
2 or 3
3
frequency, phase and voltage matching
active power (kW) / reactive power (VAR) sharing (analog)
active power and power factor control
analog input to control active power set-point externally
generator protection
selectable control outputs for speed and voltage biasing
compatible with a wide range of govenors and voltage regulators
circuit breaker time compensation
configuration via HMI or PC
password protection
Accessories
- Toolkit:
- Pramertization via Woodward’s standard Software Toolkit.
- Download link
- Back-Panel mounting option:
- Adapter enabling to mount the relays inside cabinets
- Part number: 8923-1023
- Gaskets for a front panel mounting:
- Front panel mounting comes with IP42; to increase to IP54 a gasket is required.
- Part number: 8923-1037
Downloads and Support
- Product Specification:
- Knowledgebase – FAQ
- Control Configuration Files
